Neighbor Gateway Worksheet Information
The following is a description of the information that needs to be
gathered for the worksheets that follow in this chapter. This
information is used in chapters 6, 7, and 8 for configuring nodes.
Neighbor Gateways Worksheet Information
-----------------------------------------------------------------------------
| |
| Gateway name Enter the name of a gateway that is on the same |
| network as the node that you are configuring. (Nodes |
| are on the same network if the network portions of |
| their IP addresses are the same.) Each gateway name |
| can be as long as eight alphanumeric characters. The |
| first character must be alphabetic. |
| |
| New name (Required only when renaming an existing gateway.) |
| Enter a gateway name to represent a neighbor gateway. |
| This new gateway name is used in place of the current |
| gateway name for an existing gateway configuration. |
| The name can contain as many as eight alphanumeric |
| characters. The first character must be alphabetic. |
| |
| Configured This is a list of gateways that are configured. |
| Gateways Gateway names are automatically entered in these |
| fields when they are entered above. |
| |
-----------------------------------------------------------------------------
Neighbor Gateway Configuration Worksheet
Fill out the following worksheet for each neighbor gateway you are
configuring.
![[]](../../pic3k/M013399/FFN163c50.gif)
Figure 4-7. Neighbor Gateway Configuration
