The Network Directory Data screen (#10) in Figure 11-5 “Network Directory Data” is displayed when you press the [Add]
or the [Modify] function key at the Select Node
Name screen (#9) in Figure 11-4 “Network Directory Select Node Name”. Figure 11-5 Network Directory Data
![[Network Directory Data]](img/gfx50.gif)
The function of this screen is to configure path report data
for the node name listed at the top of the screen. One path report
is configured for each NI on a node. Because the maximum number
of NIs per node is eleven (twelve including loopback), each node
can contain as many as eleven path reports. | | | |  | NOTE: NS/SNA is no longer offered as a product and has been
removed from the Corporate Price List. The product is obsolete with
no plans for support. | | | | |
Verify that the yes and no indicators in
the TCP, Checksum for TCP required,
and PXP fields are set correctly. In the IP address field,
type in the IP address of the node listed in the Node name
field. In the type field,
enter the number that indicates the type of the path: | 1 = IP | | 2 = LAN/IEEE 802.3 (LAN, 100VG, 100BT) | | 3 = X.25 ACCESS | | 4 = NS/SNA | | 5 = ETHERNET (LAN 100VG, 100BT) | | 6 = Token Ring, 100VG/IEEE 802.5 | | 7 = FDDI |
If appropriate for the type of path you are configuring,
enter an address in the Additional Address
field. (Type 1 requires no additional
address. Types 2, 5,
and 6 require a station address.
Type 3 requires an X.25 address
key. Type 4 requires an LU name.)
See additional explanation under "Fields." Press the [Save Data] key. Repeat steps 2, 3, and 4 for each path report for the
specified node.
If you need to make additional entries in the network directory,
press the [Prior Screen] key to return to the Network
Directory Select Node Name screen. If you have finished making network
directory entries, home the cursor and type EXIT
in the command field, then press [ENTER]. Fields- Transport services
These three fields describe the transport services
that should be configured in each path. - TCP
TCP must be Y (yes)
for all nodes. The default is Y. - Checksum for TCP
The checksum setting indicates whether checksumming
is optional (N) or required (Y)
for TCP. If this field is set to N,
then the use of checksums is not requested when communicating with
this node. If this field is set to Y
then checksums are used when communicating with this node. Checksumming
is required for communication to non-HP systems. The default is
N. - PXP
PXP must be Y (yes)
for all nodes. The default is Y.
Note that the selection of transport services here must match
the settings in the remote node's configuration file. If
the checksum enabled field in the path NETXPORT.GPROT.TCP
of this node is set to Y, then
TCP checksum field in the network directory should also be set to
Y. - IP address
One IP address should be entered for each network
interface configured on the remote node that is directly reachable
from this node. Each address must match an IP address configured
in the remote node's configuration file. The path of the
screen in the configuration file that contains IP addresses is NETXPORT.NI.NIname.PROTOCOL.IP. - Type
A number indicating the type of path to configure: - 1
Select this path type when the NI type is ROUTER
(Point-to-Point); or when the NI type is LAN
and the destination node supports probe or ARP; or when the NI type
is TOKEN or FDDI
and the destination node supports ARP. - 2
Select this path type when the NI type is LAN,
100VG-AnyLAN or 100Base-T,
the destination node does not support probe, and 802.3 framing is
used. - 3
Select this path type when the NI type is X25. - 4
NS/SNA is no longer offered as a product and has
been removed from the Corporate Price List. - 5
Select this path type when the NI type is LAN,
100VG-AnyLAN or 100Base-T,
the destination node does not support ARP or probe, and Ethernet
framing is to be used. - 6
Select this path type when the NI type is TOKEN
and the destination node does not support ARP. - 7
Select this path type when the NI type is FDDI and
the destination node does not support ARP.
Table 11-1 Path Type
Configuration | N1 Type | Framing | Protocols | Type |
|---|
| Point-to-Point (Router) | N/A | N/A | 1 | | LAN, 100VG-AnyLAN, or 100Base-T | 802.3 and Ethernet | Either Probe or ARP | 1 | | 802.3 and Ethernet | Neither Probe nor ARP | 5 | | 802.3 only | Not Probe | 2 | | Ethernet only | Not ARP | 5 | | X.25 | N/A | N/A | 3 | | NS/SNA | N/A | N/A | 4 | | Token Ring | N/A | ARP | 1 | | N/A | Not ARP | 6 | | FDDI | N/A | ARP | 1 | | N/A | Not ARP | 7 |
- Additional address
A lower-level address, which depends on the type. Type 1 does not
contain lower-level addressing information. You can leave the field
blank, or enter the keyword NONE. Types 2, 5,
6, and 7
require the destination node's station address, which is
a string of six hexadecimal bytes, separated by dashes (XX-XX-XX-XX-XX-XX).
The station address must correspond to the address configured on
the remote node. Type 3 requires an X.25 address
key, which is an ASCII string of up to 15 characters. The X.25 address
key must correspond to an X.25 address key entered in the NETXPORT.NI.NIname.PROTOCOL.X25.SVPATH
or the NETXPORT.NI.NIname.PROTOCOL.X25.PVCPATH
screen for the destination node. Type 4 requires the destination
node's LU name. The LU name is taken from the host generation
file of the IBM computer to which this HP 3000 is connected.
|
