SNA/Token Ring/iX Configuration

This section describes the AS/400 configuration parameters that must be
specified in order for the AS/400 to communicate with an HP 3000 on a
token ring network.

Display Line Description

This portion of the AS/400 configuration describes the connection between
the AS/400 and the HP 3000.

MAXFRAME              (Maximum frame size) Must match the MAX DATA value
                      configured on the HP 3000 SNA Node Configuration:
                      PU Data screen.

ADPTADR               (TRLAN local adapter address) Must match the Remote
                      Station Address value configured on the HP 3000 SNA
                      Node Configuration:  Token Ring Link Data screen.

SSAP                  (TRLAN source service access points) Contains all
                      source service access points available for this
                      token ring line description.

Display Controller Description

This portion of the AS/400 configuration describes each HP 3000 as a node
in the token ring network.

EXCHID                (Exchange identifier) Must match the ID BLK and ID
                      NUM values configured on the HP 3000 SNA Node
                      Configuration:  PU Data screen.

DSAP                  (TRLAN DSAP) Must match the Local SSAP value
                      configured on the HP 3000 SNA Node Configuration:
                      Token Ring Link Data screen.

SSAP                  (TRLAN source service access point) Must match the
                      Remote DSAP value configured on the HP 3000 SNA
                      Node Configuration:  Token Ring Link Data screen.

ADPTADR               (TRLAN remote adapter address) Must match the Local
                      Station Address value configured on the HP 3000 SNA
                      Node Configuration:  Token Ring Link Data screen.
                      Obtain this value from the HP 3000 system
                      administrator.

RMTCPNAME             (Remote control point name) Must match the Local
                      Control Point Name on the HP 3000 SNA Node
                      Configuration:  PU Data screen in an APPN
                      environment.
