The X.25 User Facility Sets screen (#164) in Figure 7-6 "X.25 User Facility Sets" is displayed when you press the [Go To FACSET] function key at the General X.25 Configuration screen (Figure 7-5 "General X.25 Protocol Screen"). It is also displayed when you type the path name:

@NETXPORT.NI.NIname.PROTOCOL.X25.FACSET

in the Command window of any screen and press the [Enter] key, where NIname is a configured X.25 NI.

Figure 7-6 X.25 User Facility Sets

[X.25 User Facility Sets]

To edit an existing X.25 facility set, enter the name of the X.25 facility set to be modified and press the [Modify] function key. To add a new X.25 facility set, enter a new facility set name and press the [Add] function key.

You may configure up to 128 User Facility Sets under an X.25 NI.

Fields

Set name

This name defines a set of X.25 parameters that can be associated with an SVCPATH or a PVCPATH. The name can contain as many as eight alphanumeric characters. The first character must be alphabetic.

New name

This field is used to rename a facility set. Enter the current name in the set name field. Enter the new name in the new name field and press the [Rename] function key.

The name can contain as many as eight alphanumeric characters. The first character must be alphabetic.
