General Formats (Cont.) The MOVE Statement Function. The MOVE statement transfers data, in accordance with the rules of editing, to one or more data areas. General Formats. Format 1.Format 2.Directives. 1. In addition to system directives which provide flagging and modify the reserved word list, the following directives may impact either the syntax or semantics described in this section. See your COBOL System Reference for details. * BYTE-MODE-MOVE - impacts the behavior of MOVE statements in which the sending and receiving items share a part of their storage (that is, overlapping moves). * DBCS (DBSPACE) - impacts what characters are used for space filling DBCS receiving items. * DE-EDIT - controls whether the value of numeric-edited sending fields is determined by their PICTURE clause or not. * TRUNC - determines when the sending item includes a value larger than a binary receiving values size, whether truncation occurs based on the storage available or the PICTURE clause. Syntax Rules. All Formats. 1. Identifier-1 and literal represent the sending area; identifier-2 represents the receiving area. 2. An index data item or pointer data item or procedure pointer item, (MF and VSC2 only) cannot appear as an operand of a MOVE statement. (See the section The USAGE Clause earlier in this chapter). 3. For VSC2 and MF only: If either the sending or receiving item is a DBCS (USAGE DISPLAY-1) item, then both must be DBCS items. The figurative constant SPACE can be the DBCS sending item. Format 1. 4. For OSVS, VSC2 and MF only: When Format 1 is specified, all identifiers can be either group or elementary items. The data in the sending area is moved into the data item referenced by each identifier-2 in the order in which it is specified. 5. For MF only: Identifier-1 may be a numeric function-identifier. Format 2. 6. CORR is an abbreviation for CORRESPONDING. 7. When the CORRESPONDING phrase is used, all identifiers must be group items. 8. For VSC2 and MF only: A pointer data item can be part of a group that is referenced to in a MOVE CORRESPONDING statement; however, no movement of the pointer data item will take place. General Rules. All Formats. 1. For MF only: If identifier-1 is a numeric function-identifier, then identifer-2 must be either a numeric or numeric edited item. 2. The data designated by the literal or identifier-1 is moved to the data item referenced by each identifier-2, in the order in which it is specified. The rules referring to identifier-2 also apply to the other receiving areas. Any subscripting or indexing associated with identifier-2, is evaluated immediately before the data is moved to the respective data item. For ANS85 only: If identifier-1 is reference modified, subscripted, or is a function- identifier, the reference modifier, subscript, or function-identifier is evaluated only once, immediately before data is moved to the first of the receiving operands. The result of the statement: MOVE a(b) TO b, c(b) is equivalent to: MOVE a(b) TO temp *MOVE temp TO b *MOVE temp TO c(b) where temp is an intermediate result item provided by your COBOL system. 3. Any MOVE in which the sending and receiving items are both elementary items is an elementary move. Every elementary item belongs to one of the following categories: numeric, alphabetic, alphanumeric, numeric edited, alphanumeric edited or floating-point (VSC2, OSVS, and MF). These categories are described in the PICTURE clause. Numeric literals belong to the category numeric, and nonnumeric literals belong to the category alphanumeric. The figurative constant ZERO belongs to the category numeric when moved to a numeric or numeric-edited item. The figurative constant ZERO belongs to the category alphanumeric in all other cases. The figurative constant SPACE belongs to the category alphabetic. All other figurative constants belong to the category alphanumeric. The following rules apply to an elementary move between these categories: a. i. The figurative constant SPACE, or an alphanumeric edited, or alphabetic data item must not be moved to a numeric or numeric edited data item. ii. A numeric edited data item must not be moved to a numeric or numeric edited data item. For ANS85 only: This restriction is removed. b. A numeric literal, the figurative constant ZERO, a numeric data item or a numeric edited data item must not be moved to an alphabetic data item. c. A non-integer numeric literal or a non-integer numeric data item must not be moved to an alphanumeric or alphanumeric-edited data item. d. All other elementary moves are legal and are performed according to the rules given in General Rule 5. 4. Any necessary conversion of data from one form of internal representation to another takes place during legal elementary moves, along with any editing specified for ,or de-editing implied by, (ANS85) the receiving data item: a. When an alphanumeric edited or alphanumeric item is a receiving item, alignment and any necessary space filling takes place as defined in the section Standard Alignment Rules in the chapter Concepts of the COBOL Language. If the size of the sending item is greater than the size of the receiving item, the excess characters are truncated on the right after the receiving item is filled. If the sending item is described as being signed numeric, the operational sign will not be moved; if the operational sign occupies a separate character position (see the section The SIGN Clause earlier in this chapter), that character will not be moved and the size of the sending item will be considered to be one less than its actual size (in terms of standard data format characters). b. When a numeric or numeric edited item is the receiving item, alignment by decimal point and any necessary zero-filling takes place as defined in the section Standard Alignment Rules in the chapter Concepts of the COBOL Language, except where zeros are replaced because of editing requirements. For ANS85 only: When the sending operand is numeric edited, de-editing is implied to establish the operand's unedited numeric value, which can be signed; then the unedited numeric value is moved to the receiving field. The effect of de-editing depends on the setting of the DE-EDIT directive (see your COBOL System Reference for details). When a signed numeric item is the receiving item, the sign of the sending item is placed in the receiving item. (See the section The SIGN Clause earlier in this chapter.) Conversion of the representation of the sign takes place as necessary. If the sending item is unsigned, a positive sign is generated for the receiving item. When an unsigned numeric item is the receiving item, the absolute value of the sending item is moved and no operational sign is generated for the receiving item. When a data item described as alphanumeric is the sending item, data is moved as if the sending item were described as an unsigned numeric integer. When the receiving item is numeric or numeric-edited and the sending item is defined as alphanumeric, if the content of the sending item is not an integer, the results of the move are undefined. If the alphanumeric sending item is a literal whose contents do not represent an integer, an error will be reported, and zero moved to the target. (See the section Incompatible Data earlier in this chapter.) For ANS85 only: When the numeric data item is the sending item the action of the move will be such that a reverse of the move would cause the same value to appear in the numeric edited field (except for truncation). If the data item contains data which does not conform to the edited picture, zero is moved to the target. c. When a receiving field is described as alphabetic, justification and any necessary space-filling takes place as defined in the section Standard Alignment Rules in the chapter Concepts of the COBOL Language. If the size of the sending item is greater than the size of the receiving item, the excess characters are truncated on the right after the receiving item is filled. d. For OSVS, VSC2, and MF only: When the receiving field is floating-point, the sending item is converted first to internal floating-point and then moved. When data is moved to or from an external floating-point item, the data is converted first to or from its equivalent internal floating-point value. e. For VSC2, and MF only: When the receiving field is DBCS the sending item must also be DBCS; no conversion takes place. If the sending and receiving items are not the same size the data item will be either truncated or padded with DBCS spaces on the right. 5. Any move that is not an elementary move is treated exactly as if it were an alphanumeric to alphanumeric elementary move, except that no conversion of data from one form of internal representation to another takes place. In such a move, the receiving area will be filled without consideration for the individual elementary or group items contained in either the sending or receiving area, except as noted in the General Rules of the OCCURS clause. 6. Table 4-13 summarizes the legality of the various types of MOVE statements. The general rule reference indicates the rule that prohibits the move or the behavior of a legal move. Format 2. 7. If the CORRESPONDING phrase is used, selected items in identifier-1 are moved to selected items in identifier-2, according to the rules given in the section The CORRESPONDING Phrase earlier in this chapter. The results are the same as if the user had referred to each pair of corresponding identifiers in separate MOVE statements. For OSVS and VSC2 only: The process is repeated for each destination group. Table 4-13 : MOVE Statement Data Categories ------------------------------------------------------------ | | | Category Category of Receiving Data Items (1) | | of | | Sending | | Item | | | ------------------------------------------------------------ | | | Alphabetic Alpha- Numeric Numeric- DBCS | | numeric- Integer Edited | | Edited Non- External | | Alpha- Integer Interanl | | numeric Floating | | Point | | | | Alphabetic Yes/4c Yes/4a No/3a No/4a No/4e | | | | Alpha- Yes/4c Yes/4a Yes/4b(2) Yes/4b No/4e | | numeric | | | | Alpha- Yes/4c Yes/4a No/3a No/3a No/4e | | numeric- | | Edited | | | | Numeric: No/3b Yes/4a Yes/4b Yes/4b No/4e | | Integer | | | | Non- No/3b No/3c Yes/4b Yes/4b No/4e | | Integer | | | | Numeric- No/3b Yes/4a Yes/4b Yes/4b No/4e | | Edited | | | | DBCS No/4e No/4e No/4e No/4e Yes/4e | | | ------------------------------------------------------------ (1) The relevant rule number is quoted in these columns (2) An error will be reported if a non-integer alphanumeric literal sending item is used The MULTIPLY Statement Function. The MULTIPLY statement causes numeric data items to be multiplied and sets the values of data items equal to the results. General Formats. Format 1.Format 2.Syntax Rules. All Formats. 1. Each identifier must refer to a numeric elementary item, except that in Format 2 each identifier following the word GIVING must refer to either an elementary numeric item or an elementary numeric edited item. 2. Each literal must be a numeric literal. 3. The composite of operands, which is that hypothetical data item resulting from the superimposition of all receiving data items aligned on their decimal points, must not contain more than 18 digits. 4. For OSVS, VSC2, and MF only: Floating-point data items and literals can be used anywhere a numeric data item or literal can be specified. General Rules. All Formats. 1. See the sections The ROUNDED Phrase, The ON SIZE ERROR Phrase, Arithmetic Statements, Overlapping Operands and Multiple Results In Arithmetic Statements in this chapter. Format 1. 2. When Format 1 is used, the value of identifier-1 or literal-1 is multiplied by the value of identifier-2. The value of the multiplier (identifier-2) is replaced by this product; similarly for each successive occurrence of identifier-2 in the left-to-right order in which identifier-2 is specified. Format 2. 3. When Format 2 is used, the value of identifier-1 or literal-1 is multiplied by identifier-2 or literal-2 and the result is stored in the data item referenced by each identifier-3. For MF only: The NEXT SENTENCE Statement Function. The NEXT SENTENCE statement transfers control to the next COBOL sentence, that is, following the next period. It does not transfer control to the logically next COBOL verb as occurs with the CONTINUE verb. General Format.Syntax Rule. The NEXT SENTENCE statement can be used anywhere a conditional statement or an imperative-statement can be used. General Rule. The NEXT SENTENCE statement redirects the flow of the program to the logically next COBOL verb following the next period. For OSVS only: The NOTE Statement Function. The NOTE statement introduces a sentence or paragraph that will be treated as comments. General Format.Syntax Rule. The character-string can be any combination of characters from the computer character set. General Rules. 1. If a NOTE statement is the first sentence of a paragraph, the entire paragraph is treated as comment. 2. If a NOTE statement appears as other than the first sentence of a paragraph, text up to the next separator period is treated as comment. For OSVS only: The ON Statement Function. The ON statement allows selective execution of procedural statements on a periodic basis. General Format.Syntax Rules. 1. Identifier-1, identifier-2 and identifier-3 must describe unsigned integer numeric elementary items. 2. Literal-1, literal-2 and literal-3 must be unsigned numeric literals. General Rules. 1. Prior to the first execution of each ON statement in the program, a counter, implicitly defined for that ON statement (the implicit-ON-counter), is initialized to be zero. 2. Identifier-1, identifier-2 and identifier-3 should, if specified, contain positive integer values at the time of execution of the ON statement. Varying these values between executions of the ON statement will affect subsequent executions of the ON statements. 3. The implicit ON counter cannot be affected in any way other than by transfer of program execution flow to that ON statement. (The ON counter of a called program can only be reset by the cancelling of that program; execution of the EXIT PROGRAM statement and subsequent CALL of the program without intervening CANCEL has no effect upon the implicit ON counter value.) 4. The following value-list is then evaluated: a. the current value of identifier-1 or literal-1, b. a sequence of values being the results of repeatedly adding the current value of identifier-2 or literal-2 to the current value of identifier-1 or literal-1 until the value of identifier-3 or literal-3 is reached. The implicit-ON-counter is then compared with each of this list of values. If an equality is found, then imperative- statement-1 is executed. If no equality is found, then imperative-statement-2 if specified, is executed.
![[]](../../pic3k/M015064/FFN2403c50.gif)
![[]](../../pic3k/M015064/FFN2413c50.gif)
![[]](../../pic3k/M015064/FFN2423c50.gif)
![[]](../../pic3k/M015064/FFN2433c50.gif)
![[]](../../pic3k/M015064/FFN2443c50.gif)
![[]](../../pic3k/M015064/FFN2453c50.gif)
![[]](../../pic3k/M015064/FFN2463c50.gif)
