General Formats (Cont.) For ANS85 only: The CONTINUE Statement Function. The CONTINUE statement is a no operation statement, indicating that no executable statement is present. General Format.Syntax Rule. The CONTINUE statement can be used anywhere a conditional statement or an imperative-statement can be used. General Rule. The CONTINUE statement has no effect on the execution of the program. The DELETE Statement Function. The DELETE statement logically removes a record from a mass storage file. It can be specified only for files with relative or indexed organization. General Format.Syntax Rules. 1. The INVALID KEY phrase must not be specified for a DELETE statement which references a file in sequential access mode. 2. The INVALID KEY phrase must be specified for a DELETE statement which references any file not in sequential access mode for which an applicable USE AFTER STANDARD EXCEPTION PROCEDURE is not specified. For MF, VSC2 and OSVS only: This rule is not enforced . General Rules. 1. The associated file must be open in the I/O mode at the time of execution of this statement. (See the section The OPEN Statement later in this chapter.) 2. For files in sequential access mode, the last input-output statement executed for file-name-1 prior to the execution of the DELETE statement must have been a successfully executed READ statement. The operating system logically removes from the file the record that was accessed by that READ statement. 3. For a file in random or dynamic access mode, the operating system logically removes from the file that record identified by the contents of a KEY data item associated with file-name. For a relative file, this KEY data item is the RELATIVE KEY and for an indexed file, it is the prime RECORD KEY. If the file does not contain the record specified by the key, an INVALID key condition exists. (See the section The INVALID KEY Condition in this chapter.) 4. After the successful execution of a DELETE statement, the identified record is logically removed from the file and can no longer be accessed. 5. The execution of a DELETE statement does not affect the contents of the record area associated with file-name-1. 6. The file position indicator is not affected by the execution of a DELETE statement. 7. Execution of the DELETE statement causes the value of the specified FILE STATUS data item, if any, associated with the file-name to be updated. (See the section I/O Status earlier in this chapter.) 8. Transfer of control following the successful or unsuccessful execution of the DELETE operation depends on the presence or absence of the optional INVALID KEY phrase and NOT INVALID KEY phrase (ANS85 only) in the DELETE statement. (See the section The INVALID KEY Condition in this chapter). 9. For ANS85 only: The END-DELETE phrase delimits the scope of the DELETE statement. (See the section Explicit And Implicit Scope Terminators in the chapter Concepts of the COBOL Language. . 10. For MF only: When using DELETE, the record to be deleted must not be locked by another run unit. 11. For MF only: Following the successful execution of a DELETE statement, any record lock held by the run unit on the deleted record is released. 12. Execution of the DELETE statement causes the value of the I/O status associated with file-name-1 to be updated. (See the section I/O Status earlier in this chapter.) For MF only: The DELETE FILE Statement Function. The DELETE FILE statement physically removes the specified files from the physical devices on which they reside. General Format.General Rules. 1. The DELETE FILE statement physically removes the specified files from the physical devices on which they reside. 2. The specified files must be closed when the statement is executed, but not CLOSED WITH LOCK. The DISPLAY Statement Function. The DISPLAY statement causes data to be transferred from specified data items to the appropriate hardware device, such as the CRT screen. For MF only: The DISPLAY statement also transfers data from your program to the CRT or video terminal screen: non-scrolling forms, into which you can enter data, are displayed. General Formats. Format 1.Format 2 (MF).For MF only: Format 3.Syntax Rules. Format 1. 1. The mnemonic-name must be associated with a function-name in the SPECIAL-NAMES paragraph in the Environment Division. See General Rule 9 in the section The SPECIAL-NAMES Paragraph in this chapter for a list of valid function-names. 2. For OSVS, VSC2, and MF only: Alternatively, function-name can itself be used instead of an associated mnemonic-name. 3. Each literal can be any figurative constant, except ALL. 4. If the literal is numeric, it must be an unsigned integer. For OSVS, VSC2 and MF only: This restriction can be ignored. 5. For MF and XOPEN only: When mnemonic-name is associated with ARGUMENT-NUMBER, then identifier-1 or literal-1 must each, if used, reference a data item defined as an unsigned integer or an unsigned integer literal respectively. Only a single identifier-1 or literal-1 can be used and the WITH NO ADVANCING phrase can not be used . 6. For MF and XOPEN only: When mnemonic-name is associated with ENVIRONMENT-NAME or ENVIRONMENT-VALUE, then identifier-1 or literal-1 must each, if used, reference an alphanumeric data item or a nonnumeric literal respectively. Only a single identifier-1 or literal-1 can be used and the WITH NO ADVANCING phrase can not be used. 7. The ON EXECPTION and NOT ON EXCEPTION phrases can only be specified when mnemonic-name is associated with ENVIRONMENT-NAME or ENVIRONMENT-VALUE. For MF only: Format 2. 8. Screen-name cannot be an item with an OCCURS clause. For MF only: Formats 2 and 3. 9. The LINE and COLUMN phrases can appear in any order. 10. Integer-3 and identifier-4 must be 4 or 6 digits long. For MF only: Format 3. 11. A DISPLAY statement with an operand that is not a screen-name is treated as a Format 3 DISPLAY statement if it has an AT phrase, an UPON phrase with the CRT or CRT-UNDEr option, a WITH phrase, or a MODE IS BLOCK phrase; or if it has no UPON phrase but the CONSOLE IS CRT clause is specified in the SPECIAL-NAMES paragraph. If it has the UPON phrase witht he CONSOLE option, or if it has no UPON phrase and the CONSOLE IS CRT clause is not specified in the SPECIAL-NAMES paragraph, it is treated as a Format 1 DISPLAY statement. 12. The phrases following the identifier can be in any order. 13. Elementary data items in identifier-1 must be of USAGE DISPLAY. 14. No elementary item in identifier-1 may be longer than 8191 bytes. If the MODE IS BLOCK phrase is used, the whole of identifier-1 must be no longer than 8191 bytes. 15. If a DISPLAY verb is followed by more than one identifier-1, any WITH clause applies only to the operand immediately preceding it. General Rules. Format 1. 1. When operands in a DISPLAY statement have USAGE other than DISPLAY, or have included signs, they are converted to USAGE DISPLAY with separate sign. The size of the operand is taken as the size after conversion. 2. If a figurative constant is specified as one of the operands, only a single occurrence of the figurative constant is displayed. 3. For MF only: If the function-name COMMAND-LINE, or a mnemonic-name associated with the function-name COMMAND LINE, is specified, data overwrites the contents of a system-dependent command-line buffer from where it can be retrieved by subsequent use of ACCEPT FROM COMMAND-LINE. Only one operand is allowed in this case . For MF only: All other permissible function-names are treated as equivalent to CONSOLE and each operand is transferred to the console device in the order listed. The total size of data displayed is equal to the sum of the sizes of each operand. The display starts from the current cursor position, overflowing onto the following line(s) if necessary. For MF only: On earlier releases, trailing spaces after the last operand were not displayed. 4. For ANS85 only: If the NO ADVANCING phrase is specified, the cursor is then left at the space following the last character displayed; otherwise it is positioned at the start of the next line. Scrolling can take place whenever the cursor is moved to a new line . 5. For MF and XOPEN only: If the mnemonic-name associated with the function-name ARGUMENT-NUMBER is used, then the position for any subsequent ACCEPT with a mnemonic associated with ARGUMENT-VALUE is set to retrieve the designated command-line argument. If the value associated with identifier-1 or literal-1 is less than 0, greater than 99, or greater than the total number of arguments on the command-line, then results are explicitly undefined. 6. For MF and XOPEN only: If the mnemonic-name associated with the function-name ENVIRONMENT-NAME is used then the variable to be read or set in any subsequent ACCEPT or DISPLAY with a mnemonic associated with ENVIRONMENT-VALUE is set to the designated variable-name specified in literal-1 or as the contents of identifier-1. The ON EXCEPTION phrase is ignored. If any problems occurs while trying to set an ENVIRONMENT-NAME for a subsequent ACCEPT or DISPLAY associated with ENVIRONMENT-VALUE, then it is only the subsequent ACCEPT or DISPLAY that must detect the ON EXCEPTION condition. 7. For MF and XOPEN only: If the mnemonic-name associated with the function-name ENVIRONMENT-VALUE is used then a. If a previous DISPLAY with a mnemonic-name associated with an ENVIRONMENT-NAME has been done, then the value of the identifier is placed into the designated environment-variable. b. If no previous DISPLAY with a mnemonic-name associated with an ENVIRONMENT-NAME has been performed, or, for ACCEPT, if the specified environment-variable does not exist, or, for DISPLAY, not enough space can be allocated to store the environment variable, the imperative statement associated with an ON EXCEPTION phrase is executed. The value in identifier is undefined in this case. 8. For MF and XOPEN only: If the mnemonic-name associated with the function-name SYSERR is used, then a DISPLAY is performed as if to the CONSOLE except that all output is directed to the system's standard Error Device . 9. For MF and XOPEN only: When DISPLAYing UPON ENVIRONMENT-VARIABLE, trailing spaces are included in the value. You should use INSPECT REPLACING ALL SPACE BY LOW-VALUES to avoid this. 10. For OSVS, VSC2, and MF only: Within identifier-1, internal floating-point numbers are converted to external floating-point numbers for display, so that: a. A COMP-1 item will display as if it has an external floating-point PICTURE clause of -.9(8)E-99. b. A COMP-2 item will display as if it has an external floating-point PICTURE clause of -.9(17)E-99 (even though this picture string is illegal if explicitly specified). 11. For OSVS, VSC2 and MF only: Literal-1 may be a floating-point literal. For MF only: Format 2. 12. This format of the DISPLAY statement displays screen items, which are defined in the screen section of the program, and allows full access to the enhanced screen handling facilities . For MF only: Format 2 and 3. 13. The AT phrase gives the absolute address on the screen where the DISPLAY operation is to start. 14. The order of execution of a DISPLAY statement is always: a. the AT phrase b. the BLANK phrase c. the BELL phrase d. the DISPLAY operation 15. If integer-3 or identifier-4 is 4 digits long, the first two digits specify the line, the second two the column. If 6 digits long, the first three digits specify the line, while the second three specify the column. 16. Certain combinations of line and column numbers have special meanings, as follows: a. Until the column comes within range, out of range column values are reduced by the line length and the line value is incremented. b. Out of range line values cause the screen to scroll up one line. The effect is the same as if the line number of the bottom line had been specified. c. If the line and column numbers given are both zero, the DISPLAY starts at the position following that where the preceding Format 2 or Format 3 DISPLAY operation finished. Column 1 of each line is considered to follow the last column of the previous line. d. If the line number is zero, but a non-zero column number is specified, the DISPLAY starts at the specified column, on the line following that where the preceding Format 2 or 3 DISPLAY operation finished. e. If the column number is zero, but a non-zero line number is specified, the DISPLAY starts on the specified line, at the column following that where the preceding Format 1 or 2 DISPLAY operation finished. For MF only: Format 3. 17. Part of this statement can be repeated to allow the display of several data items. If the first identifier has no AT phrase, it begins at line 1, column 1. Each subsequent data item begins at the current cursor position as left after the previous data item. 18. If identifier-1 is a group item and no MODE IS BLOCK phrase exists, those elementary subordinate items which have names other than FILLER are displayed. They are displayed simultaneously, positioned on the screen in the order their descriptions appear in the Data Division, and separated by the lengths of the FILLER items in the group. For this purpose, the first position on a line is regarded as immediately following the last position on the previous line. 19. The MODE IS BLOCK phrase indicates that the identifier is to be treated as an elementary item. Thus, even if it is a group item it is displayed as one item. 20. The WITH phrase allows you to specify certain options available during the operation. (See the section The Screen Section earlier in this chapter for descriptions of these clauses.) In addition to the options available as screen description clauses, the following options can be used in the WITH phrase; SPACE-FILL, ZERO-FILL, LEFT-JUSTIFY, RIGHT-JUSTIFY TRAILING-SIGN and UPDATE. ZERO-FILL appears in this list and as a screen description clause because it has two different uses. Its second use is documented later in this chapter. A configuration option is available which allows the entry of data into numeric and numeric edited screen fields in free format mode. In COBOL, nonedited numeric data items are intended for holding data in an internal form; however, this format enables such data items to appear on the screen. See your COBOL System Reference for more details. If free format mode is in effect, the data will appear automatically reformatted as follows: * with the virtual decimal point represented by a period * with the sign represented by a sign character ("-" for minus; space for plus) which appears immediately before the leftmost digit * with zero suppression in all integer character positions, except the least significant * with left justification The SPACE-FILL, ZERO-FILL, LEFT-JUSTIFY, RIGHT-JUSTIFY and TRAILING-SIGN options amend this format. 21. If the literal-1 is one of the following figurative constants it has a special effect as follows: SPACE clears from the specified cursor position to the end of the screen; LOW-VALUE moves the cursor to the specified position; ALL X"01" clears from the specified cursor position to the end of the line; ALL X"02" clears the whole screen; ALL X"07" sounds the bell. If the identifier is a figurative constant that is not listed above and the SIZE option is not specified, one occurrence of its value is displayed. 22. If the SIZE option is specified for a figurative constant that has no special effect, then that figurative constant is displayed as many times as necessary to reach the length specified in the SIZE option. However, if the display wraps around to a new line, it starts again at the beginning of the figurative constant. 23. If both the BLANK SCREEN and FOREGROUND-COLOR options are specified, the designated color becomes the default foreground color. 24. If both the BLANK SCREEN and BACKGROUND-COLOR options are specified, the designated color becomes the default background color. 25. If REDEFINES is used within identifier-1, the first description of the redefined data area is used and subsequent descriptions are ignored. If OCCURS or nested OCCURS are used the repeated data item is expanded into the full number of times it occurs, so that one definition is repeated for many fields. The DIVIDE Statement Function. The DIVIDE statement divides one numeric data item into others and sets the values of data items equal to the quotient and remainder. General Formats. Format 1.Format 2.Format 3.Format 4.Format 5.Syntax Rules. All Formats. 1. Each identifier must refer to an elementary numeric item, except that any identifier associated with the GIVING or REMAINDER phrase must refer to either an elementary numeric item or an elementary numeric edited item. 2. Each literal must be a numeric literal. 3. The composite of operands, which is the hypothetical data item resulting from the superimposition of all receiving data items (except the REMAINDER data item) of a given statement aligned on their decimal points, must not contain more than eighteen digits. 4. For OSVS, VSC2, and MF only: When Format 1, 2, or 3 is used, floating-point data items and literals can be used anywhere a numeric data item or literal can be specified. When format 4 or is used, no floating-point data items or literals may be specified. General Rules. All Formats. 1. See the sections The ROUNDED Phrase, The ON SIZE ERROR Phrase, Arithmetic Statements, Overlapping Operands and Multiple Results In Arithmetic Statements in this chapter; and the sections Explicit and Implicit Scope Terminators in the chapter Concepts of the COBOL Language and Delimited Scope Statements in the chapter Concepts of a COBOL Program . See also General Rules 7 and 9 for a presentation of the ROUNDED phrase and the ON SIZE ERROR phrase as they pertain to Formats 3, 4 and 5. Format 1. 2. When Format 1 is used, literal-1 or the value of the data item referenced by identifier-1 is stored in a temporary data item. The value in this temporary data item is then divided into the value of identifier-2. The value of the dividend (the value of the data item referenced by identifier-2) is replaced by this quotient; similarly, the temporary data item is divided into each successive occurrence of identifier-2 in the left-to-right order in which identifier-2 is specified. Format 2. 3. When Format 2 is used, the value of identifier-1 or literal-1 is divided into identifier-2 or literal-2 and the result is stored in each data item referenced by identifier-3. Format 3. 4. When Format 3 is used, the value of identifier-1 or literal-1 is divided by the value of identifier-2 or literal-2 and the result is stored in each data item referenced by identifier-3. Formats 4 and 5. 5. Formats 4 and 5 are used when a remainder from the division operation is desired, namely identifier-4. The remainder in COBOL is defined as the result of subtracting the product of the quotient (identifier-3) and the divisor from the dividend. If identifier-3 is defined as a numeric edited item, the quotient used to calculate the remainder is an intermediate field which contains the unedited quotient. If ROUNDED is used, the quotient used to calculate the remainder is an intermediate field which contains the quotient of the DIVIDE statement, truncated rather than rounded. 6. In Formats 4 and 5, the accuracy of the REMAINDER data item (identifier-4) is defined by the calculation described above. Appropriate decimal alignment truncation (not rounding) will be performed for the content of the data item referenced by identifier-4, as needed. 7. When the ON SIZE ERROR phrase is used in Formats 4 and 5, the following rules pertain: a. If the size error condition occurs on the quotient, no remainder calculation is meaningful. Thus, the contents of the data items referenced by both identifier-3 and identifier-4 will remain unchanged. b. If the size error condition occurs on the remainder, the contents of the data item referenced by identifier-4 remains unchanged. However, as with other instances of multiple results of arithmetic statements, the user will have to do his own analysis to recognize which situation has actually occurred.
![[]](../../pic3k/M015064/FFN2073c50.gif)
![[]](../../pic3k/M015064/FFN2083c50.gif)
![[]](../../pic3k/M015064/FFN2093c50.gif)
![[]](../../pic3k/M015064/FFN2103c50.gif)
![[]](../../pic3k/M015064/FFN2113c50.gif)
![[]](../../pic3k/M015064/FFN2123c50.gif)
![[]](../../pic3k/M015064/FFN2133c50.gif)
![[]](../../pic3k/M015064/FFN2143c50.gif)
![[]](../../pic3k/M015064/FFN2153c50.gif)
![[]](../../pic3k/M015064/FFN2163c50.gif)
![[]](../../pic3k/M015064/FFN2173c50.gif)
