Descriptions of Directives (cont.) OPT Specifies the level of optimization of the code produced in the .obj file. Syntax:.Parameters:. integer 0, 1, or 2. Default:. OPT"2" Phase:. Generate Environment:. 16-bit $SET:. Any Dependencies:. If OPT"0", set to OPT"1" at end by EANIM, GANIM or OMF"GNT". OPT"0" sets NOOBJLITE and NODATALIT at end. Remarks:. The possible values of integer are: 0 Intermediate code as produced by the first pass of the Compiler. This is generally smaller than native code, but is slower for processor-bound operations. Programs compiled with OPT"0" cannot be linked with the static linked run-time system, LCOBOL. 1 Standard generated native code. 2 Optimized generated code. Optimization does not change the logic of your program, but there might be incidental effects because some statements might have no associated machine code and statement order is not preserved. For example, PERFORM n TIMES of an empty paragraph causes no code to be generated, so this construct cannot be used to form a delay loop. OPTIONAL-FILE Makes the Compiler treat all files opened for I-O or EXTEND as optional. Syntax:.Parameters:. None Default:. OPTIONAL-FILE Phase:. Syntax check Environment:. All $SET:. Initial Dependencies:. Set to OPTIONAL-FILE immediately by NORM. Set to NOOPTIONAL-FILE immediately by RM or RM"ANSI". Remarks:. Under ANSI'85 Standard COBOL, a file is treated as optional only if it has the OPTIONAL phrase in its SELECT statement. For compatibility with the ANSI'85 Standard you must specify the NOOPTIONAL-FILE directive. OPTSIZE Makes the Compiler treat the size of the object program as a higher priority than its speed, within the constraints imposed by other directives. Syntax:.Parameters:. None Default:. OPTSIZE Phase:. Generate Environment:. 16-bit $SET:. Initial Remarks:. The directives OPTSPEED and OPTSIZE are alternates. Hence, if you don't want OPTSIZE specify OPTSPEED. OPTSPEED Makes the Compiler treat the speed of the object program as a higher priority than its size, within the constraints imposed by other directives. Syntax:.Parameters:. None Default:. OPTSIZE Phase:. Generate Environment:. 16-bit $SET:. Initial Remarks:. The directives OPTSPEED and OPTSIZE are alternates. Hence, if you don't want OPTSPEED specify OPTSIZE. Other directives such as TRUNC also affect the speed of the program. OSEXT Tells the Compiler what extension to expect by default on the names of source files. Syntax:.Parameters:. ext The extension. Default:. OSEXT"cbl" Phase:. Syntax check Environment:. All $SET:. Any Remarks:. The extension is added if the source file-name used in the command or prompt does not have an extension or a trailing period. This happens only if the directive is specified in cobol.dir. It is also used if you specify a source file-name with no extension or trailing period in a COPY statement. The Compiler searches first for the file with the name given by adding the extension specified in this directive. If none is found, it adds the extension .cpy and looks again. If that is not found it searches for the file with no extension. See also:. COPYEXT OSVS Specifies that words reserved in IBM OS/VS COBOL are to be treated as reserved words. Syntax:.Parameters:. None Default:. NOOSVS Phase:. Syntax check Environment:. All $SET:. Initial Dependencies:. OSVS sets NODOSVS immediately See also:. DOSVS OVERRIDE Replaces a reserved word by a new one. Syntax:. On DOS, Windows and OS/2:On UNIX:Parameters:. rsv-word Existing reserved word. user-word Any COBOL word not the same as an existing reserved word. Default:. No change of reserved words takes place. Phase:. Syntax check Environment:. All $SET:. Initial Remarks:. This directive equates an existing reserved word to the specified user-defined word, so that, in the program, user-word is treated as a reserved word, and rsv-word is treated as a user-defined word. The equals signs must be surrounded by spaces. If the parameters are repeated they must be separated by spaces. This directive does not appear in the list created with the SETTING directive. PANVALET Allows ++INCLUDE statements in your program. Syntax:.Parameters:. None Default:. NOPANVALET Phase:. Syntax check Environment:. All $SET:. Any Remarks:. The ++INCLUDE statement specifies a file for inclusion in the source program. The string ++INCLUDE must be written as a contiguous sequence of characters starting in area-A or area-B, followed by one or more spaces, and then, on the same line, by the name of a file containing COBOL source. This file is included in the program at the point where the ++INCLUDE statement appears. If you specify PANVALET and LIBRARIAN together, a warning message is given advising that the compiled program might not be mainframe-compatible. PARAMCOUNTCHECK Allows the program to be called with fewer parameters than are specified in the relevant entry-point's USING clause. Syntax:.Parameters:. None Default:. NOPARAMCOUNTCHECK (with OMF"OBJ") PARAMCOUNTCHECK (with OMF"GNT") Phase:. Generate Environment:. 16-bit $SET:. Initial Remarks:. You must use this directive if one of the following applies: * The program is called with a variable number of parameters * The program contains a Linkage Section, and is to be used both as a main program run from the command line and as a subprogram called from another program * The program calls any program compiled with STICKY-LINKAGE"2" specified Otherwise the program can be compiled with NOPARAMCOUNTCHECK for efficiency. A program to be called from a language other than COBOL must be compiled with NOPARAMCOUNTCHECK. Unless you specify the LINKCHECK directive, attempting to reference a Linkage Section item that does not exist might result in a system hang on DOS, or a protection violation on OS/2. See also:. LINKCHECK, STICKY-LINKAGE PARAS Creates a list of paragraphs and sections in a program. Syntax:.Parameters:. None Default:. NOPARAS Phase:. Generate Environment:. 16-bit $SET:. Initial Remarks:. Specifying PARAS causes the generated code addresses of all paragraphs and sections to be produced. This list is placed in the listing file specified by the ASMLIST directive. The assembler listing that is normally in this file is suppressed if PARAS is specified. The ANIM directive must also be specified for the PARAS directive to work. See also:. ASMLIST, ANIM PC1 Specifies that words reserved in IBM COBOL 1.00 are to be regarded as reserved words, and changes the behavior of certain features to be compatible with that product. Syntax:.Parameters:. None Default:. NOPC1 Phase:. Syntax check Environment:. All $SET:. Initial Dependencies:. PC1 sets DEFAULTBYTE"0" and ACCEPTFRESH immediately. Remarks:. This directive is synonymous with the IBM-MS and MS"1" directives. PERFORM-TYPE Specifies the behavior of return jumps from nested PERFORM statements. Syntax:.Parameters:. dialect MF, OSVS, or RM. Default:. PERFORM-TYPE"MF" Phase:. Syntax check Environment:. All $SET:. Initial Dependencies:. PERFORM-TYPE"OSVS" sets TRICKLE at end Remarks:. The possible values of dialect are: MF Only the exit point of the innermost PERFORM currently being executed is recognized and its return jump taken. OSVS The exit point of any PERFORM statement currently being executed is recognized if reached; the return jump taken is the first reached. PERFORM statements with the same exit point can be nested to a depth of two (one inner and one outer). If they are nested deeper, they do not return correctly. The end of a section is regarded as the same point as the end of its last paragraph. PERFORM-TYPE"OSVS" provides compatibility with the mainframe behavior of OS/VS COBOL, DOS/VS COBOL, VS COBOL II and COBOL/370. RM The exit point of any PERFORM statement currently being executed is recognized if reached; the return jump taken is the first reached. PERFORM statements with the same exit point cannot be nested; if they are they do not return correctly. The end of a section is regarded as a separate point from the end of its last paragraph. See also:. STICKY-PERFORM PREPLIST Causes the list file produced during a compilation to show both the original and modified source created by the preprocessor as well as to show all data passed to the Compiler by a preprocessor. Syntax:.Parameters:. None Default:. NOPREPLIST Phase:. Syntax check Environment:. All $SET:. No Remarks:. This directive is provided as a debugging aid to preprocessor writers. PREPROCESS Makes the Compiler take the source program from a preprocessor instead of a source file. Syntax:.Parameters:. nam The preprocessor to use. dir Directives to be passed directly to the preprocessor. Default:. NOPREPROCESS Phase:. Syntax check Environment:. All $SET:. On very first source line only No (with NOPREPROCESS) Remarks:. This directive informs the Compiler that an integrated preprocessor is to be used. See the chapter Integrated Preprocessor for details of its use. PRINT Specifies the destination of the source listing file. Syntax:.Parameters:. destination A full file specification, or a device-name. Default:. NOPRINT Phase:. Syntax check Environment:. All $SET:. Any Remarks:. PRINT is synonymous with LIST. All rules that apply to LIST also apply to PRINT. See also:. LIST PRINT-EXT Specifies the extension to be added to the file-name associated with the ASSIGN TO PRINTER clause. Syntax:.Parameters:. extension The extension to be added. Default:. No extension is added Phase:. Syntax check Environment:. All $SET:. Any Remarks:. This directive is ignored unless ASSIGN-PRINTER() is specified with no file-name. See also:. ASSIGN-PRINTER PROFILE Includes code in your program to produce detailed performance statistics each time you run the program. Syntax:.Parameters:. None Default:. NOPROFILE Phase:. Syntax check Environment:. UNIX $SET:. No PROGID-COMMENT Allows comments following the Program-ID in the Program-ID paragraph. Syntax:.Parameters:. None Default:. NOPROGID-COMMENT Phase:. Syntax check Environment:. All $SET:. Initial Remarks:. This directive is provided for compatibility with earlier versions of this product. PROTECT-LINKAGE Enables a subprogram to read a larger area of data than is actually passed in the Linkage Section, without causing a protection violation. Syntax:.Parameters:. None Default:. NOPROTECT-LINKAGE Phase:. Syntax check Environment:. All $SET:. Initial Remarks:. This directive is used when the subprogram is compiled. It causes code to be inserted whenever an alphanumeric linkage item is referenced as a sending item. This code ensures that the operation succeeds, even if there is less data actually available than that referenced by the linkage item. Example:. Calling program: ... 03 x1 pic x. 03 x2 pic x(100). procedure division. ... call subprog using x1 ... Subprogram: $set protect-linkage working-storage section. 01 y1 pic x(1000). linkage section. 01 z1 pic x(1000). procedure division using z1. move z1 to y1 * This operation works, and transfers the contents of x1. It also * transfers any data following x1 in the calling program, up to * 1000 bytes or the end of allocated memory, whichever occurs * first. If less than 1000 bytes is transferred, the remainder * of y1 is space filled. move y1 to z1 * This operation is not protected and fails, either by corrupting * data beyond x1 in the calling program, or attempting to write * beyond allocated memory, which results in a protection * violation.
![[]](../../pic3k/M015153/FFN2003c50.gif)
![[]](../../pic3k/M015153/FFN2013c50.gif)
![[]](../../pic3k/M015153/FFN2023c50.gif)
![[]](../../pic3k/M015153/FFN2033c50.gif)
![[]](../../pic3k/M015153/FFN2043c50.gif)
![[]](../../pic3k/M015153/FFN2053c50.gif)
![[]](../../pic3k/M015153/FFN2063c50.gif)
![[]](../../pic3k/M015153/FFN2073c50.gif)
![[]](../../pic3k/M015153/FFN2083c50.gif)
![[]](../../pic3k/M015153/FFN2093c50.gif)
![[]](../../pic3k/M015153/FFN2103c50.gif)
![[]](../../pic3k/M015153/FFN2113c50.gif)
![[]](../../pic3k/M015153/FFN2123c50.gif)
![[]](../../pic3k/M015153/FFN2133c50.gif)
![[]](../../pic3k/M015153/FFN2143c50.gif)
![[]](../../pic3k/M015153/FFN2153c50.gif)
![[]](../../pic3k/M015153/FFN2163c50.gif)
![[]](../../pic3k/M015153/FFN2173c50.gif)
![[]](../../pic3k/M015153/FFN2183c50.gif)
![[]](../../pic3k/M015153/FFN2193c50.gif)
