PRINT Statement (Executable)

The PRINT statement only transfers data from memory to the standard
output unit.  (FORTRAN unit 6 is preconnected to the standard output
device.)




----------------------------------------------------------------------------------------------
|                              |                              |                              |
|             Item             |     Description/Default      |         Restrictions         |
|                              |                              |                              |
----------------------------------------------------------------------------------------------
|                              |                              |                              |
| fmt                          | Format designator.           | See "Semantics".             |
|                              |                              |                              |
----------------------------------------------------------------------------------------------
|                              |                              |                              |
| implied_do_list              | An implied DO loop.  Refer   | None.                        |
|                              | to "DO Statement             |                              |
|                              | (Executable)".               |                              |
|                              |                              |                              |
----------------------------------------------------------------------------------------------

Semantics

The format designator must be one of the following:

   *   The statement label of a FORMAT statement.

   *   An INTEGER*4 variable to which the statement label of a FORMAT
       statement has been assigned by an ASSIGN statement.

   *   A character or noncharacter array name that contains the
       representation of a format specification.  The use of a
       noncharacter array is an extension to the ANSI 77 standard.

   *   A character expression that evaluates to a valid format string.
       Variable format descriptors are allowed only in character constant
       expressions.

   *   An asterisk to specify list-directed output (refer to
       "List-Directed Input/Output" ).

Each item in the list of data to be transferred must be one of the
following:

   *   A constant
   *   A variable name
   *   An expression
   *   An array name
   *   An array element
   *   A substring
   *   A scalar record field name
   *   An implied DO loop

The PRINT statement is equivalent to the TYPE statement.

                     Examples                                     Notes

--------------------------------------------------------------------------------------

     PRINT 10,num,des                               num and des are printed according
                                                    to FORMAT statement 10.

     PRINT *,'x=',x                                 'x=' and the value of x are
                                                    printed according to list-directed
                                                    formatting.

     INTEGER fmt                                    rat and cat are printed according
     ASSIGN 200 TO fmt                              to FORMAT statement 200.
     PRINT fmt,rat,cat

     PRINT '(4I3)',i,j,k*2,330                      i, j, k*2, and the constant 330
                                                    are printed according to the
                                                    format specification in the PRINT
                                                    statement itself.

     PRINT 100                                      The character constant in the
100 FORMAT ("End of report")                        FORMAT statement is printed.

     PRINT '(" x   SIN(x)    COS(x)"//(I3,2F7.3))', Prints a literal heading and 73
    +(i,SIN(i/57.3),COS(i/57.3),i=0,360,5)          rows of values as indicated by the
                                                    implied DO in the output list.
